Rolling

For sheets and plates

Questions? Contact one of our helpful sales managers.

Bertsch Roller

10′ to 12″ Roll

StandardStainless
48″15″
ThicknessWidth (max)Diameter (min)Width (max)Diameter (min)
0.500″87.000″20.5″73.875″22.0″
0.625″49.500″20.5″40.125″22.0″
0.750″31.375″20.5″26.000″22.0″
0.875″22.000″20.5″18.375″22.0″
1.000″16.500″20.5″13.750″24.0″
1.125″12.750″21.4″10.750″27.0″
1.250″10.250″23.8″8.625″30.0″
1.375″8.375″26.2″7.000″33.0″
1.500″7.000″28.5″5.875″36.0″
Thickness16 ga. – 114
I.D. (min)16″
O.D. (max)13′
Width7″ – 120″
Rolling Tolerance±18
Concentricity±316

Cylinders are tack welded, then rerolled to avoid flat spots. We can also roll without tack welding.


Why Liebovich?

  • Quick turnaround and on-time performance
  • No parts minimums — from 1 to 1,000+ pieces
  • Save on labor, machining, forming and time
  • One-stop shopping from material to finished part
  • Reduce your scrap, increase your profits
  • Additional processing available to meet your finished part needs
